Flora Lux Sensor - TSL2561 Light Sensor

9.58 11.59 VAT included
Rated 0/5 (0 Votes!)
Model: ADFC-1246
Manufacturer: Adafruit
Adafruit

Add light-reactive sensing to your wearable Flora project with this high precision Lux sensor. The TSL2561 luminosity sensor is an advanced digital light sensor, ideal for use in a wide range of light situations. Compared to low cost CdS cells, this sensor is more precise, allowing for exact lux calculations and can be configured for different gain/timing ranges to detect light ranges from up to 0.1 - 40,000+ Lux on the fly. The best part of this sensor is that it contains both infrared and full spectrum diodes! That means you can separately measure infrared, full-spectrum or human-visible light. Most sensors can only detect one or the other, which does not accurately represent what human eyes see (since we cannot perceive the IR light that is detected by most photo diodes)

The sensor has a digital (I2C) interface. Attaching it to the flora is simple: line up the sensor so its adjacent to the SDA/SCL pins and sew conductive thread from the 3V, SDA, SCL and GND pins. They line up perfectly so you will not have any crossed lines. You can only connect one lux sensor to your Flora, but you can connect other I2C sensors/outputs by using the set of SCL/SDA pins on the opposite side. The current draw is extremely low, about 0.5mA when actively sensing, and less than 15 uA when in powerdown mode.

Check our our Flora Lux Sensor tutorial, the conventional TSL2561 tutorial, and you can use our Arduino library-- the example and library code will work 'out of the box' with Flora.

https://www.youtube.com/embed/I-bhAN6wqXk

https://www.youtube.com/embed/kiBbRU5rwQc

//www.youtube.com/embed/5avUvKLEiLs?rel=0&start=1010&autoplay=0

Flora Lux Sensor - TSL2561 Light Sensor (16:50)

For more information, please visit this products webpage.
